LiFePO4 Battery Management System: Improving Battery Performance and Safety

May 12, 2023

A LiFePO4 Battery Management System (BMS) is an essential device in managing batteries, especially in small and portable electronic devices. It ensures that batteries are maintained and charged correctly while also prolonging battery life. In this article, we will discuss the importance of LiFePO4 BMS and how it can improve battery performance while ensuring safety.

lifepo4 battery management system

What Is A LiFePO4 BMS?

The Lithium iron phosphate battery system functions optimally with the aid of a BMS, which plays a crucial role in preserving the health and performance of the cells within the battery pack. It is essential to operate the battery within its designated ranges of current, voltage, and temperature, as deviation from these ranges may lead to permanent damage to the components and unsafe scenarios. The battery comes with an inbuilt BMS to ensure protection from these eventualities.

The LiFePO4 BMS is responsible for managing the charge and discharge processes for LiFePO4 battery packs. Whenever there is a deviation from the specifications, the BMS protection feature instantly activates and modifies the charging parameters or cuts off the power flow within the battery pack. It also monitors the battery cells to confirm they are functioning collectively, measures current, voltage, and temperature parameters to guarantee optimal operation and promote safety.

The BMS is also instrumental in preventing your battery pack from overcharge, overvoltage, overcurrent, over-temperature, and cell imbalance, which reduces its life cycle. Furthermore, utilizing a BMS optimizes the battery capacity and overall performance in every charge and discharge process, thus enhancing the lifespan and performance of the LiFePO4 battery pack.

The Function of Battery Management System

Protecting Current:

Monitoring the current and cell or module voltages of a battery pack is crucial for ensuring its safety. The safe operating area of a battery cell is determined by its voltage and current levels, which are influenced by its intrinsic chemistry and temperature.

In Lithium Iron Phosphate batteries, the charging and discharging current limits are typically set by battery cell manufacturers. While higher peak currents can be handled for short periods, a maximum continuous current limit is imposed by the Battery Management System (BMS) designed for these batteries to prevent unsafe conditions.

Moreover, sudden changes in load conditions are taken into account. The BMS may also include peak current monitoring by integrating the current and deciding whether to reduce the available current or interrupt the pack current to respond instantly to extreme current peaks. The BMS ensures that multi-cell batteries remain balanced by equalizing their voltages, which prevents overcharging or over-discharging of individual cells, minimizing the risk of reduced capacity and shortened lifespan.

Redodo-24V-200Ah-lithium-battery

Protecting Voltage

A Battery Management System (BMS) is responsible for ensuring that the voltage of a battery pack remains within a safe operating range, thus preventing damage or shortened lifespan. The BMS employs a range of methods to protect the battery's voltage, including:

Continuous Voltage Monitoring: The BMS continuously monitors the battery pack's voltage using sophisticated sensors or other measurement devices. The measured voltage is compared to predetermined safe limits, and corrective measures are taken if the voltage falls outside this range.

  1. Overvoltage Safety: The BMS effectively prevents overvoltage by limiting charging current or stopping charging altogether. When the battery reaches its maximum safe voltage, the BMS will turn off the charging circuit to prevent further charging and damage to the battery.
  2. Undervoltage Protection: Similarly, the BMS protects the battery from undervoltage by preventing over-discharging. The BMS acts by interrupting the discharge process if the battery's voltage drops below a certain level, thus preventing damage to the battery.
  3. Balancing: In the case of multi-cell batteries, the BMS provides voltage balancing by equalizing their voltages, preventing overcharging or over-discharging of individual cells. This significantly minimizes the risk of reduced capacity and shortened lifespan.

The safe operating area (SOA) limits of Lithium-Ion batteries are primarily influenced by their intrinsic chemistry and temperature. As battery packs undergo significant current cycling due to discharging from load demands and charging from various energy sources, these SOA voltage limits are often further restricted to optimize battery lifespan. The BMS must evaluate the battery's limits and make decisions based on their proximity to these thresholds.

For example, when the battery approaches its high voltage limit, the BMS may gradually reduce the charging current or halt the charging altogether upon reaching the limit. However, intrinsic voltage hysteresis considerations are often taken into account to prevent control chatter near the shutdown threshold. Conversely, approaching the low voltage limit requires the BMS to request major active offending loads to reduce their current demand.

Temperature Safety:

The BMS ensures that the battery temperature stays within safe limits by continuously monitoring the temperature of the battery pack with sensors or other measurement devices. Thermal management techniques such as passive cooling, active cooling, or heating are implemented to regulate the temperature. If the battery temperature exceeds its safe range limit, the BMS may limit the charging or discharging rate or shut down the battery to prevent permanent damage.

Over Charge/Discharge Protection:

Monitoring voltage and current during the charging and discharging processes are critical in protecting the battery from overcharge and over-discharge. The BMS uses different methods such as limiting current or voltage, state-of-charge estimation, multi-cell balancing, and temperature monitoring to regulate the safe operating range of the battery.

The Protection of Short Circuit

Unpredictable short circuits can harm the battery and connected devices immediately. Continuous monitoring of voltage and current levels enables the BMS to take the appropriate measures, such as limiting charging and discharging rates, disconnecting overheating or overvoltage cells, and using fuses and circuit breakers to shut down the system. Fault detection systems identify wiring, connection, or other component issues that can cause short circuits. The BMS quickly reacts to prevent further damage.

In conclusion, the BMS plays a vital role in protecting rechargeable batteries from overcharge, over-discharge, overheating, short circuits, and unexpected events, enhancing their performance, extending lifespan, and improving safety.

Can I Charge A LiFePO4 Battery Without A BMS?

While it may be possible to charge a LiFePO4 battery without a BMS, it is strongly discouraged due to the potential dangers involved. Supplying the battery with a charging voltage or current higher than recommended can result in thermal runaway, which can result in a fire or explosion, making this practice hazardous.

To ensure the safety of the battery, it is recommended to closely monitor the charging conditions such as voltage, current, and temperature. You may use voltage and amperage meters and temperature sensors for your battery cells for this purpose. By monitoring these factors closely, you can adjust the conditions to prevent the battery from undergoing undue stress.

However, not using a BMS will negatively impact your battery's lifespan. The use of a BMS guarantees optimized working conditions, and without this monitoring, the battery will not last as long as it otherwise would. Therefore, it is always best to use a BMS to ensure the battery's optimal performance and longevity.

The Redodo batteries are equipped with an integrated BMS that provides comprehensive protection against the most typical causes of battery malfunctions and hazards. By guarding the cells against the possibility of short circuits, high currents, extreme temperatures and voltage fluctuations, the BMS guarantees that the battery operates with utmost safety and efficiency.

Conclusion

In conclusion, a LiFePO4 Battery Management System (BMS) offers a comprehensive range of functions that provide vital safety and performance enhancements for rechargeable batteries, especially in small and portable electronic devices. With the BMS's ability to monitor parameters such as current, voltage, temperature, and preventing overcharging and over-discharging, it helps to extend the life of batteries and enhance the safety of its users.

lifepo4 bms battery management system

Although possible to charge a LiFePO4 battery without a BMS, it is strongly discouraged due to potential hazards. It is best to use a BMS to optimize battery performance and longevity.

At Redodo, our batteries are equipped with an integrated BMS that provides comprehensive protection against typical causes of battery malfunctions and hazards. This guarantees that the battery operates with maximum safety and efficiency.

 -----------------------------------------------------------------------------------------------------
